Caliber for Combo tester Caliber of bracelet and shoe tester
We will stock the goods 2-3 weeks after receiving the order
127,95 EUR / incl. VAT
Description
- Dimensions: 190 x 150 x 55 mm.
- Weight: 150 g.
- Accuracy of set limits: ±1%.
Working temperature: 0 to 55°C.
The Combo tester calibrator is a device designed to calibrate testers of protective grounding bracelets, their leads and shoes, which are used in antistatic workplaces in a reserved area according to EN 61 340-5-1. The mentioned standard prescribes a daily check of the suitability of these bracelets and shoes by a tester, which must be calibrated at least once a year.
The caliber for the Combo tester is set to the upper and lower limits of the limits below with an accuracy of 1%:
| Input | Lower limit "FALSE" | Lower limit "TRUE" | Upper limit "TRUE" | Upper limit "FALSE" |
|---|---|---|---|---|
| Bracelet | 7,5 x 105Ω - 2,5 x 104Ω | 7,5 x 105Ω + 2,5 x 104Ω | 3,5 x 107Ω - 1,0 x 106Ω | 3,5 x 107Ω + 1,0 x 106Ω |
| Lead to bracelet | 7,5 x 105Ω - 2,5 x 104Ω | 7,5 x 105Ω + 2,5 x 104Ω | 5,0 x 106Ω - 1,5 x 105Ω | 5,0 x 106Ω + 1,5 x 105Ω |
| Basic footwear | 5,0 x 104Ω - 1,0 x 104Ω | 5,0 x 104Ω + 1,0 x 104Ω | 3,5 x 107Ω - 1,0 x 106Ω | 3,5 x 107Ω + 1,0 x 106Ω |
| Additional footwear | 5,0 x 104Ω - 1,0 x 104Ω | 5,0 x 104Ω + 1,0 x 104Ω | 1,0 x 108Ω - 3,0 x 106Ω | 1,0 x 108Ω + 3,0 x 106Ω |
Description:
The caliber of the Combo tester is structurally solved in a plastic box. The input sockets, switches of the controlled limits and buttons "TRUE - green" and "FALSE - red" are on the top panel of the device. The calibration evaluation indicates a calibrated tester that connects with the gauge to the appropriate input terminals of the tester. When the interval is set, the button is pressed and the light corresponding to the color of the caliber button lights up on the correctly set tester. Otherwise, the tester must be brought within the relevant limits. Connecting wires are included in the delivery.
Package contents
Caliber for Combo tester Caliber of bracelet and shoe tester
