PS-Control 100 power supply

• Power supply: 230 VAC ± 10%, 50 Hz.
• Working temperature: 10 – 35 °C.
• Working air humidity: < 85% RH, non-condensing.
• Dimensions: 210 x 130 x 145 mm.
• Speed ​​control: HI – LO.
• Output current constant: 3 A.
• Output current peak: 5 A.
• Operation indication: yellow light.
• Indication of reaching the set torque: red light.
• Adjustable number of torque reaches: 1 - 99.
• The source is designed in a metal box.
• The power supply and fuse are on the rear panel.
• The output connector and indicator lights for connection, operation and torque are located on the front panel.
• Controls - main switch and speed switch - are also on the front panel.
• The output voltage is stabilized with the possibility of regulation in two stages.
• The output current is switched by a thyristor.

The source is intended for powering HIOS and HIMAX industrial torque screwdrivers. It enables the setting of the number of torques (number of tightening) and control of the rotation speed in two steps. They have an indication of the screwdriver running and reaching the set torque. The source with the screwdriver can be integrated into the automated line.
